Screwing systems Bench for the hardware and sash assembly on the shutters


technical information

  • RAL 7042 / RAL3000 painted metal structure
  • Extensible support surface in aluminium
  • Work surface covered in felt
  • Sash clamp with 2 lateral fittings, one fixed fitting and one movable, by means of a pneumatic actuator with patterns for hardware cutting
  • Self-powered screwdriver with pivoting screw feeder
  • Screw loading system and screwing controlled by electronic PLC
  • Screwing depth regulator
  • Compatibility with glazed and unglazed sashes and sashes with one or more sash bars


  • Net usable area: minimum 300 mm / maximum 2800 mm
  • Width: 3000 mm
  • Depth: 1250 mm
  • Height: 900 mm
  • Cycle time: 1 sash h 1500 mm: 240/300 “


  • Handle hole FM
  • Hardware cutter TF
  • Horizontal hardware store FO / vertical FV / with hardware digital recognition MF
L'immagine è inserita a scopo illustrativo The image is inserted for illustrative purposes L'image est insérée à titre illustratif Das Bild wird zu Illustrationszwecken eingefügt
